Vehicle Mounted Mobile Riot Control Isolation Fence Concertina Razor Wire Security Defense Barrier

Vehicle Mounted Mobile Riot Control Isolation Fence Concertina Razor Wire Security Defense Barrier

A rapid deployment system for razor barbed wire, towed by a vehicle, featuring flexible and efficient operation

●Provides rapid barrier deployment, capable of laying 200 meters of razor barbed wire barrier in just 5 minutes

●Easy to operate, requiring only 2 to 3 workers to complete the deployment. After the mission, the barrier can be quickly retrieved.

●Available in two configurations: 3D coils (1.7 m) and 6D coils (2.3 m).

Razor barbed wire is not just a static barrier. It can also be a mobile security system

The razor barbed wire making machine is a flagship product of MeiRun. Over more than 20 years of deep involvement in the razor barbed wire industry, MeiRun has been closely watching its market. Most customers purchase razor barbed wire to use it as a static barrier, such as reinforcing fences with razor barbed wire coils or welding razor barbed wire into fences, which are relatively limited in application. The mobile security razor barbed wire trailer launched by MeiRun turns razor barbed wire into a mobile security system. With a vehicle towing it, this trailer can deploy 200 meters of razor barbed wire in just 5 minutes, quickly setting up a secure barrier and creating an impenetrable protective net. The entire deployment process is simple, efficient, and does not require many workers. It can play a vital role in public emergency situations, such as protests, demonstrations, riots, temporary facility protection, traffic control, and similar scenarios.

3D Mobile Security Razor Barbed Wire Trailer

This model is primarily equipped with 3D pyramid-shaped razor barbed wire coils. The coils are arranged in two layers, assembled in a 1+2 configuration. The coil height is 1.7 m.

6D Mobile Security Razor Barbed Wire Trailer

This model is primarily equipped with 6D pyramid-shaped razor barbed wire coils. The coils are arranged in three layers, assembled in a 1+2+3 configuration. The coil height is 2.3 m.

Multi-layer coil configuration for comprehensive isolation and protection. A highly mobile razor barbed wire trailer

The mobile trailer design not only reduces manufacturing costs but also eliminates concerns over mechanical failure, power loss, or vehicle breakdowns, ensuring superior mobility. Most vehicles, including sedans, SUVs, pickup trucks, and commercial trucks, can tow this trailer. The entire deployment and retrieval process can be completed in just 3 to 5 minutes.

Protest and demonstration control

Effectively separates protesters and demonstrators to maintain public order

Temporary facility protection

Used to protect critical locations or unopened construction sites

Traffic control

Establishes barriers at road closures or accident scenes to guide traffic

Border area lockdown

Enables rapid defensive deployment in disputed border areas to support military operations

Product Introduction

The mobile security razor barbed wire trailer, also known as a razor barbed wire barricade trailer, is a highly efficient and flexible security barrier. It can be connected to a towing vehicle via a coupling axle, allowing rapid deployment to designated locations. The trailer is equipped with 3 or 6 sets of compressed razor barbed wire coils, each 70 meters long, secured at both ends by welded metal frames. During deployment, operators simply open the rear tailgate and pull out the metal frames, and the razor barbed wire quickly unrolls automatically to form a three-dimensional barrier in just a few minutes. The mobile security razor barbed wire trailer features 100% automatic deployment and retrieval. For retrieval, the towing vehicle is shifted into reverse and moves back slowly, while the built-in chain system rewinds and compresses the razor barbed wire, ensuring it remains ready for reuse. The trailer's exterior color and logo can be customized according to customer requirements.

Lighting system

The trailer is equipped with 8 yellow indicator lights, 4 on each side, providing warning and visibility at night. The front and rear of the trailer are also fitted with working lights, along with flashing indicators on both sides to ensure adequate illumination in low-light conditions.

Practical design

The trailer features 3 windows on each side for daily ventilation and dust removal. Each trailer comes with a spare tire, and both the wheels and the coupling drawbar are adjustable.

Customizable on demand

The type, size, and coil height of the razor barbed wire loaded inside the trailer can all be customized. The default configuration is the BTO22 model, with an upper coil diameter of 98 cm and a lower diameter of 75 cm. If you have customization requirements, please send the product specifications to our staff in advance. We can supply razor barbed wire coils with diameters ranging from 45 cm to 100 cm, which will be shipped together with the trailer after production.

Complete production solutions

MeiRun is a professional enterprise specializing in razor barbed wire machinery, with its own production line and factory. If you have large-volume requirements for razor barbed wire, we can provide you with a production line combination consisting of a punching press and a wire forming machine for independent razor barbed wire production. A high-speed punching press paired with a high-speed wire forming machine can achieve a daily output of over 8 tons. The production line is highly automated, requiring only manual material handling and feeding, while the rest of the process is completed by the machines. The finished razor barbed wire can be used for multiple Trailer or sold externally for profit. If you already have your own production line or factory, you can also purchase the mobile security razor barbed wire trailer separately. MeiRun will provide you with a complete production plan and technical support to help you produce finished razor barbed wire that meets your requirements.

High-speed punching press

High-speed forming machine

Alternative product recommendations

Purchasing a mobile security razor barbed wire trailer requires a significant investment. If you are on a limited budget, MeiRun recommends the following two products. They both offer razor barbed wire barrier deployment capabilities and can meet basic needs for small-scale, three-dimensional razor barbed wire coil protection.

①Basic model razor barbed wire trailer

The basic model features an open design with two wheels, one on each side. A suspension frame is installed at the rear to hold the razor barbed wire coil. The deployment method is essentially the same as the larger trailer but at a moderate speed. It is suitable for short-to-medium distance protective barrier layouts.

②Foldable razor barbed wire security barrier

Each unit contains approximately 10 meters of razor barbed wire coil. To deploy, one person holds the telescopic frame in place while the other pulls the razor barbed wire in the opposite direction until the coil is fully extended. The foldable barrier is available in 3D or single-coil models, with specified razor barbed wire specifications. It is suitable for short-distance layouts or protective barriers in multiple non-continuous areas.

Transportation and installation support

From price inquiry to installation support, MeiRun provides a complete machine solution. We have professional experience in packaging and shipping, and can provide you with export documents and relevant customs clearance certificates. Full machine testing and performance checks are carried out before shipment to ensure proper operation. Upon arrival, you can install the machine with remote guidance and instruction manuals, and we also support dispatching engineers to the site for installation, operation, and training.

Machine parameters

Fast deployment, fast retrieval. The trailer becomes a mobile security barrier

The robust razor barbed wire coils, combined with the sharp blade design, provide a physical barrier while also delivering a strong visual deterrent, effectively stopping potential intruders.

Internal structure of the razor barbed wire assembly (3D model)

6D model

FAQ

1.Are the razor barbed wire coils inside the trailer secured properly? I'm concerned they might come loose and affect the stability of the barrier

Answer: The razor barbed wire is professionally bundled and secured before shipment. You don't need to worry - it will maintain its three-dimensional shape. Between each pair of coils, clips are installed as professional fasteners to ensure the coils remain securely in place without deformation.

2.Can people ride inside the mobile security razor barbed wire trailer?

Answer: No. The interior space is very compact and contains sharp razor barbed wire. Entering without proper precautions could easily result in injury.

3.Can the razor barbed wire coils be removed and replaced from the trailer?

Answer: Yes, the replacement process is very simple. However, you must replace them as a complete set. Individual coils cannot be removed or replaced separately, as they are integrated as one unit.

Galvanized Clips and Mobile Barrier Supports: The Key to Keeping Razor Barbed Wire Coils Intact

A 3D mobile security razor barbed wire trailer needs to carry three sets of 70-meter razor barbed wire coils. When the coils are fully deployed, how do we ensure they do not come loose or lose shape, but instead maintain a perfect three-dimensional form? This is where two tools come into play: galvanized clips and mobile barrier supports.

Galvanized clips, also known as razor barbed wire clips, are fasteners. They can bind two razor barbed wire coils together, creating an additional anchor point. Once tied, the razor barbed wire maintains its basic coil shape no matter how it is stretched. The galvanized coating ensures the clips themselves are durable and resistant to corrosion. The machines for producing galvanized clips are available from MeiRun. If you purchase finished razor barbed wire from MeiRun, the cost of the clips is already included in the order, and they are installed before delivery.

Mobile barrier supports are welded metal pipe frames, positioned in a three-dimensional arrangement. They are installed at both ends of the razor barbed wire coils to provide support. When the mobile security razor barbed wire trailer begins deployment, we first need to move the supports to the starting point, with one worker holding the support in place. The remaining razor barbed wire coils then automatically release and steadily fall to the ground as the trailer moves forward. With the help of these metal supports, the razor barbed wire coils are no longer isolated. They are less likely to become loose, lose shape, or be easily knocked over or damaged.
