Rib Lath Mesh High Ribbed Formwork

Rib Lath Mesh High Ribbed Formwork Widely used as a plaster backing on ceilings, walls and stud partitions. Rib mesh is also ideal for refurbishing damaged or aged masonry walls when a key for rendering is not certain due to disintegration or softening of the wall face. 1).Construction formwork mesh has very good engineering quality and construction security; 2).Construction formwork mesh as the concrete permanent assembly free sheet is much convenient for engineering design and processing; 3).Construction formwork mesh is widely used in tunnels,bridges and valve system and so on to make the process of construction much more fast and stable.
Thickness:
length:
Rib Distance:
Weight (KG):
Availability:
Quantity:
  • MRSKWJ

  • Meirun

Rib Lath Mesh High Ribbed Formwork

Rib Lath Mesh High Ribbed Formwork  products widely used as a plaster backing on ceilings, walls and stud partitions. Rib mesh is also ideal for refurbishing damaged or aged masonry walls when a key for rendering is not certain due to disintegration or softening of the wall face.

收口网机器123

Material:Hot-dipped galvanized sheet


Rib Lath Mesh High Ribbed Formwork  is widely used in building construction to form retaining walls, columns,stopends, construction joints and used to support slab flooring.

High Ribbed Formwork For Building Machine  is ideal for proving a high degree key of mechanical bonding with render or plaster.


收口网机

Application:



1)Rib Lath Mesh High Ribbed Formwork has very good engineering quality and construction security;



2).Rib Lath Mesh High Ribbed Formwork as the concrete permanent assembly
free sheet is much convenient for engineering design and processing;



3).Rib Lath Mesh High Ribbed Formwork   is widely used in tunnels,bridges and valve system and so on to make the process of construction much more fast and stable.

收口网产品图片12

Specification

Features of Rib Lath Mesh High Ribbed Formwork  for construction material:
1) Mechanical performance is good, the lateral pressure is small
2) Pouring process is easy seen
3) Light weight, easy to transport and install
4) Optimization of process, increase the shear interface
5) Easy to wear and continuous banding steel
6) To adapt to the segmented pouring concrete, the construction of civilization
7) The socket and cutting easy operation

Model

Thickness

(mm)

Weight (kg)

Width (mm)

Length (mm)

Rib Height(mm)

Rib Distance

(mm)

021

0.21

1.70

450

2200

14-20

90

023

0.23

1.90

450

2200

14-20

90

030

0.30

2.48

450

2200

14-20

90

035

0.35

2.90

450

2200

14-20

90

040

0.40

3.30

450

2200

14-20

90

045

0.45

3.70

450

2200

14-20

90

050

0.50

4.10

450

2200

14-20

90

Packing and delivery

收口网产品图片


Our company

装箱图片

Our customers

客户6 (1)_副本
