| Machine name : | |
|---|---|
| Machine width : | |
| Mesh hole : | |
| Availability: | |
| Quantity: | |
MRHWJ
Meirun
8463300000
| Model | MR1200 | MR1500 | MR1600 |
| Wire diameter | 2-3.5mm/2-4mm | ||
| Longitude wire space | Mostly 50-200mm(If min.25*25mm, we can also design) | ||
| Crosswire space | Min. 25mm or smaller (PLC control) | ||
| Mesh width | Max. 1200mm | Max. 1500mm | Max. 1600mm |
| Welding electrodes | 25pcs | 32pcs | 32pcs |
| Welding transformer | 125kva*3pcs | 125kva*4pcs | 125kva*4pcs |
| Longitude wire feeding | From wire coils | ||
| Crosswire feeding | Pre-straightened&pre-cut(cross wire feeder) | ||
| Welding speed | Max. 130 times/min | ||
| Space needed | 12*5m | ||
| Machine weight | 3100kg | 3600kg | 3840kg |
Roller welded product
| Model | MR1200 | MR1500 | MR1600 |
| Wire diameter | 2-3.5mm/2-4mm | ||
| Longitude wire space | Mostly 50-200mm(If min.25*25mm, we can also design) | ||
| Crosswire space | Min. 25mm or smaller (PLC control) | ||
| Mesh width | Max. 1200mm | Max. 1500mm | Max. 1600mm |
| Welding electrodes | 25pcs | 32pcs | 32pcs |
| Welding transformer | 125kva*3pcs | 125kva*4pcs | 125kva*4pcs |
| Longitude wire feeding | From wire coils | ||
| Crosswire feeding | Pre-straightened&pre-cut(cross wire feeder) | ||
| Welding speed | Max. 130 times/min | ||
| Space needed | 12*5m | ||
| Machine weight | 3100kg | 3600kg | 3840kg |
Roller welded product
