| Motor: | |
|---|---|
| Weight: | |
| Wire Diameter: | |
| Warranty: | |
| Quantity: | |
1. Manually installation, Easy to set up;
2. Steel cover on driving shaft for safety operation;
3. Saving materials and high capacity;
4. Counter to count the number of barbs and calculate length of barbed wire.
5. Button switches and leveler to start and stop machine easily.
6. Quick and easy roll extraction from the machine.
1.Warranty: One Year.
2.Enough spare parts of machines could be supplied.3.Factory Own Designing and Inspection Team.
4.All machines were tested and adjusted before delivery.
5.Engineers avaliable to service machinery overseas: Worker-training, installation.etc.
6.24 hours technical support by e-mail or calling service.
Specification
| Model | CS-A | CS-B | CS-C |
| Motor | 2.2kw | 2.2kw | 2.2kw |
| Main Drive Shaft Speed | 402r/min | 355r/min | 355r/min |
| Wire Diameter(mm) | 2.2-3.0 | 2.2-3.0 | 1.6-2.2 |
| Barbed Wire Diameter(mm) | 1.8-2.2 | 1.8-2.2 | 1.6-2.2 |
| Barbed Space(mm) | 76,102,127 | 102,127 | 102,127 |
| Twisted Number | 3-5 | - | 7 |
| Theoretical Production | 77kg/h | 40kg/h | 40kg/h |
| Weight | 1000kg | 950kg | 950kg |
| Main Part Size(mm) | 1950*950*1300 | 3100*1000*1150 | 3100*1000*1150 |
Packing & Delivery
1.The main machine is nude packing or plastic packing.
Finished Product
Company Profile
Our company is a professional screen machinery manufacturing company with many years of experience in China. Our company focuses on the manufacturing and trading of various screen products and related machines. We have our own factory and professional R&D team to ensure the quality and strict testing of the products. For some machines, our market share is as high as 70%. All of our machines are in line with international quality standards and customers' needs and have been greatly appreciated in various markets around the world. So we are your wise choice and best friend.
Company Certificate
Our Factory
