Cattle fence, also called field fence, is widely used in protecting ecological balance, prevent landslides and farm industry.
called field fence making machine adopts advanced hydraulic technique. Bending the wire,depth about 12mm, width about 40mm in every mesh to big enough buffers to preventing animals striking.
Suitable wire to the machine: hot dipped galvanized wire ( usually Zinc rate 60-100g/m2,
in some wet place 230-270g/m2)
Cattle fence making machne/ field fence making machine specification:
Power | 3.0Kv |
Wire diameter | Selvage wire diameter: 1.9mm—3.0mm Inside wire diameter: 1.8mm—4.0mm |
Width | 0.5m—2.5m |
Mesh opening | adjustable |
Machine size | 2800×2300×2300mm |
Weight | 4.0T |
Cattle fence/field fence/grassland fence specification:
No. | Item | Specification | The top and bottom wire diameter | The middle wire diameter |
1 | 7/150/813/50 | 102+114+127+140+152+178 | 2.5 | 2.0 |
2 | 8/150/813/50 | 89(75)+89+102+114+127+140+152 | 2.5 | 2.0 |
3 | 8/150/902/50 | 89+102+114+127+140+152+178 | 2.5 | 2.0 |
4 | 8/150/1016/50 | 102+114+127+140+152+178+203 | 2.5 | 2.0 |
5 | 8/150/1143/50 | 114+127+140+152+178+203+229 | 2.5 | 2.0 |
6 | 9/150/991/50 | 89(75)+89+102+114+127+140+152+178 | 2.5 | 2.0 |
7 | 9/150/1245/50 | 102+114+127+140+152+178+203+229 | 2.5 | 2.0 |
8 | 10/150/1194/50 | 89(75)+89+102+114+127+140+152+178+203 | 2.5 | 2.0 |
9 | 10/150/1334/50 | 89+102+114+127+140+152+178+203+229 | 2.5 | 2.0 |
10 | 11/150/1422/50 | 89(75)+89+102+114+127+140+152+178+203+229 | 2.5 | 2.0 |
Note: the item numbers: the first number means the number of wire of width; the second number means distance of horizontal wires (mm); the third number means the height of mesh(mm); the fourth number means length of mesh(m). we can also produce the mesh according to the customers special requirements. | ||||
