| Machine name : | |
|---|---|
| Wire diameter: | |
| Controller: | |
| Quantity: | |
Brick force wire welded mesh making machine
| Items | Parameter |
| Mesh width | 75mm, 115mm, 230mm (50-230mm adjustable ) |
| Electrode no. | 4 |
| Wire diameter | 1.6-3.5mm |
| Cross wire space | ≥20mm |
| Material | Low carbon wire ( carbon contains ≤0.2%,tensile strength ≤550MPa |
| Welding speed | 60-90 times/min. |
| Transformer | 36KVA×1set |
| Line wire feeding | Coils wire feed from coil by servo motor |
| Cross wire feeding | Coils wire feed from coil by servo motor |
| Welding pressure | Pneumatic |
| Welding method | Controlled by SCR |
| Mesh pulling | Automatic rolling machine, one time making two coils |
| Controller | PLC with touch panel |
| Mesh length setting | Automatic cut |
Brick force wire welded mesh making machine
| Items | Parameter |
| Mesh width | 75mm, 115mm, 230mm (50-230mm adjustable ) |
| Electrode no. | 4 |
| Wire diameter | 1.6-3.5mm |
| Cross wire space | ≥20mm |
| Material | Low carbon wire ( carbon contains ≤0.2%,tensile strength ≤550MPa |
| Welding speed | 60-90 times/min. |
| Transformer | 36KVA×1set |
| Line wire feeding | Coils wire feed from coil by servo motor |
| Cross wire feeding | Coils wire feed from coil by servo motor |
| Welding pressure | Pneumatic |
| Welding method | Controlled by SCR |
| Mesh pulling | Automatic rolling machine, one time making two coils |
| Controller | PLC with touch panel |
| Mesh length setting | Automatic cut |
