Machine name : | |
---|---|
Wire Diameter : | |
Drawing Speed m/min: | |
Availability: | |
Quantity: | |
MRHWJ
Meirun
8463300000
es./Type | MR9-900 | MR9-800 | MR9-700 | MR10-600 | MR10-400 |
Drum Dia./mm | 900 | 800 | 700 | 600 | 400 |
Drawing Passes/time | 9 | 9 | 9 | 10 | 10 |
Max.Inlet Wire Dia./mm | 8-14 | 8-10 | 6.5-8 | 5.5-6.5 | 1.8-2.5 |
Min.Outlet Wire Dia./mm | 3-5 | 3-4 | 2.5-3 | 1.8-2 | 0.75-1 |
Drawing Speed m/min | 300 | 360 | 480 | 750 | 840 |
Inlet Wire Strength/kg/mm2 | Max.1300 | Max.1300 | Max.1300 | Max.1300 | Max.1300 |
Total Compressibility% | 85.94-87.24 | 84-85.94 | 85.21-85.94 | 89.29-90.53 | 87.24 |
Average Compressibility% | 19.58-20.48 | 18.42-19.58 | 19.13-19.58 | 21.00-21.02 | 18.61 |
Motor Power/kW | 90-110 | 55-90 | 55-75 | 22-37 | 7.5-15 |
es./Type | MR9-900 | MR9-800 | MR9-700 | MR10-600 | MR10-400 |
Drum Dia./mm | 900 | 800 | 700 | 600 | 400 |
Drawing Passes/time | 9 | 9 | 9 | 10 | 10 |
Max.Inlet Wire Dia./mm | 8-14 | 8-10 | 6.5-8 | 5.5-6.5 | 1.8-2.5 |
Min.Outlet Wire Dia./mm | 3-5 | 3-4 | 2.5-3 | 1.8-2 | 0.75-1 |
Drawing Speed m/min | 300 | 360 | 480 | 750 | 840 |
Inlet Wire Strength/kg/mm2 | Max.1300 | Max.1300 | Max.1300 | Max.1300 | Max.1300 |
Total Compressibility% | 85.94-87.24 | 84-85.94 | 85.21-85.94 | 89.29-90.53 | 87.24 |
Average Compressibility% | 19.58-20.48 | 18.42-19.58 | 19.13-19.58 | 21.00-21.02 | 18.61 |
Motor Power/kW | 90-110 | 55-90 | 55-75 | 22-37 | 7.5-15 |
