| Machine name : | |
|---|---|
| Edge wire diameter: | |
| Knot wire diameter: | |
| Production speed: | |
| Roll mesh length: | |
| Quantity: | |
MRHWJ
Meirun
8463300000
| Model | MR-1560 | MR-1800 | MR-2400 |
| Edge wire diameter | 2.0-3.5 mm | 2.0-3.5 mm | 2.0-3.5 mm |
| Line wire diameter | 1.6-3.2 mm | 1.6-3.2 mm | 1.6-3.2 mm |
| Knot wire diameter | 1.6-2.5 mm | 1.6-2.5 mm | 1.6-2.5 mm |
| Production speed | 32 Time /min | 32 Time /min | 32 Time /min |
| Fence height | Max 1560 mm | Max 1800 mm | Max 2400 mm |
| Line wire number | Max 14 | Max 16 | Max 21 |
| Line wire spacing | 120 mm (Multiple adjust) | ||
| Cross wire spacing | 70-300 mm(Arbitrarily adjust) | ||
| Roll mesh length | 30-100 meter | ||
| Line wire testing | Automatic stop lack of wire | ||
| Cross wire testing | Automatic stop lack of wire | ||
| Knot wire testing | Automatic stop lack of wire | ||
| Control system | PLC+touch screen | ||
| Dimensions | 5000*2000*2600 mm | 5000*2300*2600 mm | 5000*2800*2600 mm |
| Weight | 2800 kg | 3200 kg | 4500 kg |
| Wire material | Iron wire, Steel wire, Galvanized wire, etc | ||
| Model | MR-1560 | MR-1800 | MR-2400 |
| Edge wire diameter | 2.0-3.5 mm | 2.0-3.5 mm | 2.0-3.5 mm |
| Line wire diameter | 1.6-3.2 mm | 1.6-3.2 mm | 1.6-3.2 mm |
| Knot wire diameter | 1.6-2.5 mm | 1.6-2.5 mm | 1.6-2.5 mm |
| Production speed | 32 Time /min | 32 Time /min | 32 Time /min |
| Fence height | Max 1560 mm | Max 1800 mm | Max 2400 mm |
| Line wire number | Max 14 | Max 16 | Max 21 |
| Line wire spacing | 120 mm (Multiple adjust) | ||
| Cross wire spacing | 70-300 mm(Arbitrarily adjust) | ||
| Roll mesh length | 30-100 meter | ||
| Line wire testing | Automatic stop lack of wire | ||
| Cross wire testing | Automatic stop lack of wire | ||
| Knot wire testing | Automatic stop lack of wire | ||
| Control system | PLC+touch screen | ||
| Dimensions | 5000*2000*2600 mm | 5000*2300*2600 mm | 5000*2800*2600 mm |
| Weight | 2800 kg | 3200 kg | 4500 kg |
| Wire material | Iron wire, Steel wire, Galvanized wire, etc | ||
